Pelican 1630 Protector Transport Case


Interior Dimensions : 70.4 x 53.3 x 39.4 cm
Exterior Dimensions : 79.4 x 61.5 x 44.4 cm
Weight With Foam : 16.3 kg
Weight Empty : 14.1 kg


Shipping Quote

Enter your postcode and suburb to generate your quote.


Sensitive equipment needs protection, and since 1976 the answer has been the Pelican™ Protector Case. These cases are designed rugged, and travel the harshest environments on earth. Against the extreme cold of the arctic or the heat of battle, Pelican cases have survived.

Made in the USA, these tough cases are designed with an automatic purge valve, that equalizes air pressure, a watertight silicone O-ring lid, over-molded rubber handles and stainless steel hardware.

  • 4 strong polyurethane wheels with stainless steel bearings (wheel diameter is 5.3cm)
  • Stackable
  • Watertight, crushproof, and dustproof
  • Reinforced corners
  • Open cell core with solid wall design – strong, light weight
  • Retractable extension trolley handle
  • 3 level Pick N Pluck™ with convoluted lid foam
  • Fold down handles
  • Easy open Double Throw latches
  • Stainless steel padlock protectors
  • Automatic Pressure Equalization Valve – balances interior pressure, keeps water out
  • O-ring seal
  • Note: Please consult a sales specialist for more details.
  • Lifetime Guarantee of Excellence


IP67 / STANAG 4280 / Def Stan 81-41

Lid Depth

3.25" (8.3 cm)

Bottom Depth

12.14" (30.8 cm)

Total Depth

15.39" (39.1 cm)

Int Volume

5.21 ft³ (0.148 m³)

Padlock Hole Diameter

Body Material


Latch Material

O-Ring Material

Pins Material

Foam Material

1.3 lb Polyurethane

Purge Body Material

Purge Vent Material

Minimum Temperature

Maximum Temperature
